Model	Content	Module Size	View	Dot	Character Size	Controller	IC Pack	Temp.	STN		Drawing
			Area	Size		or Equivalent
	Chas x Lines	W x H(mm)	W x H(mm)	W x H(mm)	W x H(mm)			Normal	Without	LED BL
C0802A	8X2	84.0X44.0	63.0X25.0	1.15X1.36	6.07X11.56	SPLC780	COB	●	●	●	C0802A
C0802B	8X2	58.0X32.0	38.0X16.0	0.56X0.66	2.95X5.56	SPLC780	COB	●	●	●	C0802B
C1202A	12X2	55.7X32.0	46.7X17.5	0.45X0.6	2.65X5.5	SPLC780	COB	●	●	●	C1202A
C1601A	16X1	80.0X36.0	64.5X13.8	0.55X0.65	3.2X5.95	SPLC780	COB	●	●	●	C1601A
C1601B	16X1	122.0X33.0	99.0X13.0	0.92X1.1	4.84X8.06	SPLC780	COB	●	●	●	C1601B
C1601C	16X1	80.0X36.0	64.5X13.8	0.6X0.7	3.2X8.2	SPLC780	COB	●	●	●	C1601C
C1601D	16X1	85.0X28.0	65.0X16.0	0.55X0.75	3.07X6.56	SPLC780	COB	●	●	●	C1601D
C1601E	16X1	80.0X36.0	64.5X13.8	0.55X0.75	3.07X6.56	SPLC780	COB	●	●	●	C1601E
C1602A	16X2	80.0X36.0	64.5X13.8	0.55X0.5	2.95X4.35	SPLC780	COB	●	●	●	C1602A
C1602B	16X2	122.0X44.0	99.0X24.0	0.92X1.1	4.84X9.66	SPLC780	COB	●	●	●	C1602B
C1602C	16X2	80.0X36.0	64.5X13.8	0.55X0.5	2.95X4.35	SPLC780	COB	●	●	●	C1602C
C1602E	16X2	85.0X36.0	64.5X15.5	0.56X0.66	2.96X5.56	SPLC780	COB	●	●	●	C1602E
C1602F	16X2	72.0X36.0	64.5X15.5	0.56X0.66	2.96X5.56	SPLC780	COB	●	●	●	C1602F
C1604A	16X4	87.0X60.0	62.0X25.6	0.55X0.55	2.95X4.75	SPLC780	COB	●	●	●	C1604A
C2002A	20X2	98.0X60.0	85.0X18.6	0.55X0.55	2.95X5.55	SPLC780	COB	●	●	●	C2002A
C2002B	20X2	116.0X37.0	83.0X18.6	0.6X0.65	3.2X5.55	SPLC780	COB	●	●	●	C2002B
C2002C	20X2	146.0X43.0	123X23.0	1.1X0.92	4.84X9.22	SPLC780	COB	●	●	●	C2002C
C2004A	20X4	98.0X60.0	76.0X25.2	0.55X0.55	2.95X4.75	SPLC780	COB	●	●	●	C2004A
C2004B	20X4	77.0X47.0	60.0X22.0	0.42X0.46	2.3X4.03	SPLC780	COB	●	●	●	C2004B
C2004C	20X4	146.0X62.5	123.5X43.0	0.92X1.1	4.84X9.22	SPLC780	COB	●	●	●	C2004C
C2402A	24X2	118.0X36.0	93.5X16.0	0.6X0.65	3.2X5.55	SPLC780	COB	●	●	●	C2402A
C2402B	24X2	208.0X40.0	178.0X23.0	1.16X1.16	6.0X9.63	SPLC780	COB	●	●	●	C2402B
C4002B	40X2	182X33.5	154X16	0.6X0.65	3.2X5.55	SPLC780	COB	●	●	●	C4002B
C4004A	40X4	190.0X54.0	147.0X29.5	0.5X0.55	2.78X4.89	SPLC780	COB	●	●	●	C4004A
G12232A	122X32	84.0X44.0	60.0X18.5	0.4X0.4	0.44X0.44	AX6120	COB	●	●	●	G12232A
G12232C	122X32	98.0X60.0	76.0X25.2	0.52X0.61	0.56X0.65	AX6120	COB	●	●	●	G12232C
G12864A	128X64	78.0X70.0	62.0X44.0	0.39X0.55	0.44X0.6	S6B0108A	COB	●	●	●	G12864A
G12864C	128X64	93.0X70.0	72.0X40.0	0.48X0.48	0.52X0.52	S6B0108A	COB	●	●	●	G12864C
G19264A	192X64	130.0X65.0	104.0X39.0	0.46X0.46	0.51X0.51	KS0107B	COB	●	●	●	N/A
G24064B	240X64	180.0X65.0	132.0X39.0	0.53X0.53	0.49X0.49	T6963C	QFP	●	●	●	G24064B
G240128A	240X128	144X104	114X64	0.4X0.4	0.45X0.45	T6963C	QFP	●	●	●	G240128A
